Building custom wheels with Forgestar is easy. Here is what you can expect:
Description
- Custom bolt patterns
- Rotary formed flow formed barrel
- Big brake kit clearance
- Wide range of wheel widths
- Superior offset range
- Drilled to cone seat specs
*Conical/tapered lug nuts will be required.
F14 FITMENT CHART
Forgestar F14 wheels are available in a wide range of sizes and offsets to accommodate various vehicle platforms and performance needs:
- Diameters: 17" to 22"
- Widths: 8.5" to 14"
- Offsets: From -81mm to +83mm
These options allow for precise fitment, whether you're aiming for a flush stance or a more aggressive setup. The wheels are also designed to clear most big brake kits, making them suitable for high-performance applications.
| SEMI CONCAVE | SEMI CONCAVE OFFSET RANGE | DEEP CONCAVE | DEEP CONCAVE OFFSET RANGE | SUPER DEEP CONCAVE | SUPER DEEP CONCAVE OFFSET RANGE | ULTRA DEEP CONCAVE | ULTRA DEEP CONCAVE OFFSET RANGE |
|---|---|---|---|---|---|---|---|
| 17×8.5 | +6 to +50 | 18x9.5 | -8 to +38 | 15x8 | -25 to 20 | 18x9.5 | -81 to -37 |
| 17×9.0 | +12 to +58 | 18×10 | -2 to +42 | 18×9.5 | -25 to +23 | 18x10 | -75 to -31 |
| 17×9.5 | +19 to +65 | 18×11 | +11 to +55 | 18×10 | -19 to +30 | 18×11 | -62 to -18 |
| 17×10 | +25 to +72 | 18×12 | +24 to +68 | 18×11 | -6 to +43 | 18×12 | -50 to -6 |
| 17x10.5 | +31 to +78 | 18×13 | +36 to +83 | 18×12 | +6 to +55 | 19×9.5 | -81 to -37 |
| 18×8.5 | +4 to +48 | 19×9.5 | +4 to +42 | 19×9.5 | -25 to +23 | 19×10 | -75 to -31 |
| 18×9.0 | +10 to +55 | 19×10 | +20 to +44 | 19×10 | -19 to +30 | 19×11 | -62 to -18 |
| 18×9.5 | +17 to +60 | 19×11 | +23 to +55 | 19×11 | -6 to +43 | 19×12 | -50 to -6 |
| 18×10.5 | +29 to +72 | 19×12 | +36 to +68 | 19×12 | +6 to +55 | 20x9.5 | -81 to -37 |
| 19×8.5 | +26 to +48 | 20×9.5 | +7 to +43 | 20×9.5 | -23 to +25 | 20x11 | -62 to -18 |
| 19×9.0 | +12 to +55 | 20×10.5 | +20 to +57 | 20×10.5 | -10 to +36 | 20x12 | -50 to -6 |
| 20×9.0 | +12 to +56 | 20×11 | +21 to +61 | 20×11 | -4 to +44 | ||
| 22×9.0 | +18 to +57 | 20×12 | +39 to +75 | 20×12 | +9 to +55 | ||
| 22×10 | +31 to 70 | 22×10.5 | +10 to +49 | 22×9.5 | -13 to +33 | ||
| 22×12 | +29 to +68 | 22×12 | +0 to +46 | 22x10.5 | +0 to +46 | ||
| 22×12 | +19 to +65 | 22x12 | +19 to +65 |
F14 Semi Deep Concave Custom Finishes
Forgestar provides a variety of finish options to complement your vehicle's look, including the finishes below. Additionally, custom finishes are available upon request, allowing for further personalization.
F14 Custom
